Description
Drive-units: 1″ (25mm) diamond-dome tweeter, 6″ (150mm) Continuum-cone FST midrange driver, two 8″ (200mm) Aerofoil-cone woofers. Crossover
frequencies: 350Hz, 4kHz.
Frequency range: 14Hz–35kHz.
Frequency response on reference axis: 17Hz–28kHz, ±3dB.
Sensitivity: 90dB/2.83V/m.
Harmonic distortion (second and third harmonics, 90dB, 1m): <1%, 80Hz–20kHz; <0.3%, 100Hz–20kHz.
Impedance: 8 ohms nominal, 3.0 ohms minimum.
Recommended amplification: 50–500W into 8 ohms on unclipped program.
Maximum recommended cable impedance: 0.1 ohm.
Dimensions: 47.3″ (1212mm) H by 15.2″ (390mm) W by 22.7″ (583mm) D. Weight: 207.9 lbs (94.5kg).
Finish: Gloss Black, Rosenut.
