Description
True class A, fully discrete analogue circuits with no negative feedback
First-order analogue filter with silvered Mica capacitor
+/- 20 VDC regulated voltage supplies for best THD and noise suppression in analogue sections
Separate custom-built Noratel toroidal transformers for digital and analogue sections
15,000 microFarad power capacitor banks per channel
Ultra-short signal path with minimal Internal wiring
Balanced analogue outputs with PCB-mounted gold-plated Swiss Neutrik XLR sockets
75 Ohm BNC S/PDIF digital output
4-line, 20 character display with user-selectable illumination (High/Medium/Low/Off)
Remote control (also for basic Atilla integrated amplifier functions)
4 x 32bit/192kHz D/A-Converters from AKM
Dual differential topology
Up-sampling to fs = 192kHz
Dual Mono
Discrete build class A analog stages
Output Level, balanced: 4Vrms
Power Supply capacity: 40.000uF
Weight, netto: 9.6 kg
