Description
D/A Converter Multi level Delta Sigma
Sampling: (f) 44.1 kHz
Digital filter: Over sampling 16 times =705, 6 kHz (44.1 kHz red book)
Switch capacitor filter: +Over sampling 128 times (smoothing)
Converter: (f) 2.82 MHz
Resolution: 24 bit linear
Error correction: Repeat block on error
Signal/ Noise-Ratio: 110 dB/ 112 dB
Digital Inputs
XLR AES/EBU: 110Ω ./.
RCA: ./.
Input impedance: 75Ω
Glas ST: ./.
TOSLINK: ./.
Digital outputs: XLR, RCA, Toslink
Output Impedance: 110Ω, 75Ω
Analog Outputs
Connection: 1 RCA, 1 XLR
Frequency Range: DC – 20 kHz, +0 / -0.5 dB
Signal to noise: 110 / 112 dBr, 2
Dynamic: 97 dB
Channel separation: 110 dB, 1 kHz
THD: 0.0007%, 1
Output level: 2V, 1kHz (RCA), 4V,1kHz (XLR)
Output Impedance: RCA= 100 Ω, XLR= 200 Ω
Power consumtion: 50 VA max
Line Voltage: 230/115 Vac, 50/60 Hz
Weight: 18 kg/ 40 lbs
Abmessungen: (WxHxD) 450 x 155 x 400 mm, 17.7 x 6.1 x 15.7 inches
