Description
Output Power: 350W into 8 Ohms, 700W into 4 Ohms, 1100W into 2 Ohms.
Frequency response: 0.15Hz–175kHz, –3dB.
Slew rate: 50V/µs.
THD and Noise: <0.015% (1kHz, 8 ohms, 20W); <0.045% (1kHz, 8 ohms, 100W); <0.06% (1kHz, 8 ohms, 200W).
Damping factor: >300, 20Hz–20kHz, 8 ohms; >90, 100kHz, 8 ohms
Output Current: 50A peak, continuous, 150A peak, 0.1 ohm, 20ms, 1kHz.
Voltage gain: 26.4 dB.
Sensitivity: 136mV, 1W into 8 ohms.
Input impedance: optional: 100k, 20k, 600 ohms
Dimensions: 19″ (480mm) wide x 8.75″ (220mm) high x 24″ (610mm) deep.
