Description
AUDIO OUTPUTS
Frequency Response: 10Hz – 20kHz, -0.6dB@20kHz
Load Impedance: 10kΩ (min.)
Analogue Outputs: DIN, RCA
Output Impedance: 10Ω (max.)
Line Outputs Fixed (level): 2.1Vrms at 1kHz
Total Harmonic Distortion + Noise: <0.007%, 10Hz – 20kHz at full level
Phase Response: Linear phase, absolute phase correct
De-emphasis: ±0.1dB referred to main response
CONNECTIVITY
Remote Control: Infrared RC5
FORMATS
Disc Compatibility: CD, CD-R
CD Formats: Red Book
USER CONTROL INTERFACES
Front Panel: Four button matrix
Handheld: Remote handheld
CABLE SPECIFIC
Connectors: DIN & RCA Connectors
POWER
Mains Supply: 100V, 115V, 230V; 50 or 60Hz
Power Consumption: 9VA (stop mode), 12VA (play mode), 16VA (peak)
PHYSICAL
Dimensions: 70 x 432 x 301mm (H x W x D)
Weight: 5.9kg
Shipping Dimensions: 200 x 580 x 500mm (H x W x D)
Shipping Weight: 8.1kg
