Description
Mains: 220 – 240 V (50 – 60 Hz), 100 – 120 V (50 – 60 Hz)
Power consumption: < 0.5 W Standby, idle 150 W, max 1600 W
Outputs: 2 pairs Cu-terminal,
gold plated
Gain: – 31 dB bis + 42 dB
Power output: 125 W @ 8 Ω, 250 W @ 4 Ω, 500 W @ 2 Ω
Pulse power: > 5,000 W
Frequency response (– 3 dB): 0 – 800 kHz
THD + N: < 0.001% at 50 W @ 4 Ω, (20 Hz – 20 kHz)
IM distortions: < 0.005 % SMPTE, < 0.0006 CCIR
Signal-to-noise ratio: > 120 dB (5 W @ 1 kHz)
Channel separation: > 110 dB @ 1 kHz
Damping factor: > 10 000
Output current max: 45 A (limited)
Inputs: 2 × balanced (XLR), 2 × unbalanced (RCA), 1 × Phono (RCA)
Input impedance: 3 kΩ balanced (XLR), 3 kΩ unbalanced (RCA), Phono configurable
Dimensions: 442 × 350 × 448 mm, (W × H × D)
Weight: approx. 40 kg
LINK (remote turn-on): 12 V control signal
